High-power spot light SF07 180-240W

APPLICATION SCOPE

The high-power spotlights are widely used in various types of ships, offshore engineering platforms, metallurgy, chemical fields, and other areas for long-range projection lighting and floodlighting.

MAIN FEATURES

● Aluminum alloy die-cast shell with high-voltage electrostatic spray anti-corrosion treatment.
● The high-power spotlight lampshade is made of tempered glass.
● Exposed fasteners are made of stainless steel.
● The light source cavity, power supply cavity, and wiring cavity are separated for convenient installation and maintenance.
● Uses high luminous efficiency, high color rendering, long-life, green, and environmentally friendly COB LED light source.
● Wide voltage input range, constant current and constant voltage power supply, constant power output, with open circuit protection, short circuit protection, and other functions.
● Multiple beam angles and light distribution curves for flexible lighting design.

STANDARDS AND CERTIFICATES

1.China Classification Society RULES FOR CLASSIFICATION OF SEA-GOING STEEL SHIPS and its revised notifications
2.IEC 60598-1 IEC 60598 IEC 60092-306
3.IEC 62722-2-1

Product outline element drawing:

LIGHT DISTRIBUTION CURVE

TYPE DESIGNATION

SF	07-	150W	-D
Spot Light/Flood Light	07 Series	Power	Angle
		180/200/240W	E:60°
			F:90°
			G:120°

TECHNICAL PARAMETERS

Product name	Spot Light/Flood Light
Power	180/200/240W
Luminous flux	18000/20000/24000lm
Efficiency	≥100lm/W
Voltage	AC100-277V 50HZ/60HZ
PF	≥0.9
Beam angle	60° 90° 120°
Ra	≥70
CCT	Cool white 5500~6500K
Corrosion-proof	WF2
Protection level	IP66
Temperature	-35~+55℃

FAQ

Q: Are you a manufacturer?

A: Yes, we are a research and development, production, and sales enterprise specializing in LED industrial lighting since 2018.

Q: Can I have a sample order for LED lights?

A: Yes, sample orders to test and check the quality are welcome. Mixed samples are acceptable.

Q: How about the lead time?

A: 5-7 days for sample orders, 15-25 days for mass production orders based on order quantities.

Q: How do you ship the finished products?

A: By sea, air, or express (DHL, UPS, FedEx, TNT, etc.) are optional.

Q: Do you have a MOQ for it?

A: Our MOQ is 1 piece.

Q: Is it OK to print my logo on it?

A: We provide OEM services to our customers and can make the label and color box according to your requirements.

Q: How to deal with defects?

A: All of our products are produced under a strict quality control system, with a defective rate of less than 0.2% according to our shipment records. We offer a 1-year warranty for this product. If there is any defect during the warranty period, please provide a picture or video showing the defective lights. We will ship new lights to you within a few days or include them with your next order.

Q: When can I get the quotation?

A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us so that we will regard your inquiry priority.

Q: How can I get a sample to check your quality?

A: After price confirmation, you can require for samples to check our quality.
If you need the samples, we would like to send sample from our Chinese factory.

Q: Can I request to change the form of packaging and transportation?

A: Yes, We can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.
